WONYO 2 Head Computerized Apparel Textile Cap Flat Embroidery Machine

Large Image : WONYO 2 Head Computerized Apparel Textile Cap Flat Embroidery Machine

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	WONYO
Certification:	CE/SGS

Contact Now

Detailed Product Description

Maximum Speed:	1000SPM	Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Condition:	New	Type:	Cap Embroidery Machine
Operation:	Computerized	Overall Dimensions:	152012701400mm
Warranty:	More Than 5 Years	Key Selling Points:	Long Service Life
Power(w):	400W	Worktable Size:	450*800mm
Head Interval:	500mm	Embroidery Area:	400*450mm
After Warranty Service:	Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service	Local Service Location:	United States, Philippines, Indonesia, Mexico, Spain, Malaysia, Morocco, Kenya, Chile, Romania, South Africa, Nigeria
Showroom Location:	United Kingdom, United States, Peru, Indonesia, Mexico, Spain, Chile, Romania, South Africa, Nigeria, Malaysia	After-sales Service Provided:	Free Spare Parts, Online Support, Video Technical Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Engineers Available To Service Machinery Overseas
XY Motor:	Stepper XY Motor	Control Panel:	Topwisdom 10 Inch LCD Screen
Belt:	Italy Brand Belt	Needles:	Groz-Beckert Needles
Bobbin Core:	Aluminum Bobbin Core	Warranty:	12 Months
Working Noise:	Lowest	Consumption:	Lowest
Speed:	1000RPM

2 Head computerized embroidery machine suitable for logo embroidery T-shirt cap and jacket

Please contact Miss Nicki Wang for details:

Whatsapp/wechat: 008618696118389

facebook: nickiemb999

Main Features

1) Suitable for flat embroidery, cap embroidery and finished garments embroidery

2) Automatic thread trimmer
3) Maximum speed 1000 RPM
4) 270 degree Wide cap frame unit
5) Color LCD display showing real time stitching
6) USB input port
7) Automatic color change
8) Thread break detection
9) Pre-sew design trace capable
10) Memory size 20, 000, 000 stitches
11) Emergency stop
12) Electricity: 110V/60Hz or 220V/50Hz available
13) Built-in bobbin winder
14) Keeping current data or work when emergency stop or power off
15) Mending function. (back and skip stitches under controller)
16) Switch of Cap/ flat embroidery mode eliminating hitting the frame.
17) USB port with fast data transmission and good compatibility
18) Mainboard intergated into control panel protecting from dust or external force.
19) Lay-out of keys on panel is user-friendly.

20) Built-in Network

Model	Q400/Q401/Q402/Q403
Operation	Computerized
Head Number	2 Heads
Needle/Color Number	6/9/12/15
Embroidery Area	400*500mm
Worktable Size	400*500mm
Head Interval	400mm
Overall Dimensions	142510301040mm
Certification	CE, SGS
After-sales Service	Engineers available to service machinery overseas
application	flat, cap, T-shirt, finished garments, logo, 3D
Package	Wooden Case
Motor	Servo and stepper motor
Warranty	24 months limited warranty with lifetime support
language	12 languages
Speed	1000RPM
Computer	10 inch LCD display and touch screen showing real time stitching

Compact Control Panel

A. Color LCD display showing real time stitching
B. Manual, Semi-auto, Auto Color Change
C. Function keys including Menu, Speed up and slow
D. Multi languages available
E. Frame-moving keys, Manual Trimming
F. DOT ket to return to 100 degree
G. Start, Stop, and emergency Stop
H. Embroidery Status (Page Up/Page Down), USB Input,
I. Parameter Settings, Clear, ESC, Enter, etc.
J. Numeric keys for selection of needles

Hoops/frames inclued

A. 1 x Shirt Front Round Hoop 9 cm (3.5")

B. 1 x Shirt Front Round Hoop 12 cm (4.7")

C. 1x Shirt Front Round Hoop 15 cm (5.9")

D. 1 x Shirt Front Round Hoop 19 cm (9")

E. 1 x Jacket Back Square Hoop 30 x 30 cm (12" x 12")

F. 1 x Sash Frame 56 x 38 cm (22" x 15")

Other Attachment:

1. Table and stander with wheels 2. Extended Table Top 3. Operation Manual 4. Tool Kit

Built-in Network:

Packing and Delivery

Package
Size	142510301040mm
Weight	470KG
Package details	The normal package is wooden box(Size: LWH). But it's ok to pack it according to customers special request.
