1. Designed for embroidery on bulky and large items, such as bags, bed sheets, drapery, towels, and more. Perfect for caps, shirts
and any other finished products.
2. Maximum speed 1200SPM
3. Small footprint for easier desktop placement
4. The newly developed small sewing arm guarantees better embroidery quality on caps and small items
5. Multi-languages available in English, Chinese, Spanish, Portuguese,Turkish, Dutch, French, German, Russian, Vietnamese, Thai,
Arabic and more.
6. User –friendly control interface with useful functions that make it easy to operate and increases efficiency.
7. Machine reads multiple design formats, such as DST, DSB and more.
8. Hoops sizes are pre-programmed to avoid hitting frames.
9. When setting color change sequence, operator is able to add applique, sequin, boring or cording. There is no need to change it
in the parameters page.
10.Built in key for auto timing points for 172 to 196. simplifies machine maintenance.
11.Frame offset and frame outlining function keys have been added to the control interface for easy appliqué embroidery and frame
change.
12.Multi-angle rotational and adjustable control panel bracket for better viewing options.
13. New ergonomic touch screen allows easy and comfortable operating by right hand thumb.
14.High Definition true color 10" LCD Touch Screen.
15. Recessed USB port to protect USB flash drive.
16. One step trace button directly on the main screen.
17. Main operation area located on the right side of interface, convenient for right thumb operation.
18. External 100° button and trimming button.
19. Suitable for flatbed embroidery, cap/hat embroidery, finished garments embroidery and more
20. Perfect for home and commercial embroidery
21. Maximum embroidery area: 360*1200mm /500*800mm/500*1200mm or 20″ x 14″
22. Automatic thread trimmer
23. 270° wide angle cap system
24. USB input or direct transmission from PC via serial port or wireless
25. Networkable and Wi-Fi capable
26. Auto color change
27. Thread break detection
28. Pre-sew design trace capable
29. Automatic memory retention
30. Servo motor 150W - the lowest power consumption in the industry
31. Built-in universal power supply, 110V/60Hz and 220V/50Hz self-adaptable worldwide
32. DC36V micro-step motor for X & Y axis driving to ensure low noise and less vibration.
33. Heavy duty steel stand with wheels to ensure both stability and mobility
34. Emergency stop
